The Martin B-57 Canberra is an American-built, twinjet tactical bomber and reconnaissance aircraft that entered service with the United States Air Force (USAF) in 1953. The B-57 is a license-built version of the British English Electric Canberra manufactured by the Glenn L. Martin Company. Initial Martin-build models were highly similar to their British-built counterparts; Martin later modified the design to incorporate larger quantities of US-sourced components and produced the aircraft in several different variants.

General characteristics

Crew: 2 (pilot,navigator )
Length: 65 ft, 6 in (20.0 m)
Wingspan: 64 ft 0 in (19.5 m)
Height: 14 ft 10 in (4.52 m)
Wing area: 960 ft² (89 m²)
Empty weight: 27,090 lb (12,285 kg)
Loaded weight: 40,345 lb (18,300 kg)
Max. takeoff weight: 53,720 lb (24,365 kg)
Zero-lift drag coefficient: 0.0119
Drag area: 11.45 ft² (1.06 m²)
Aspect ratio: 4.27
Powerplant: 2 × Wright J65-W-5 turbojets, 7,220 lbf (32.1 kN) each

Performance

Maximum speed: Mach 0.79 (598 mph, 960 km/h) at 2,500 ft (760 m)
Cruise speed: 476 mph (414 knots, 765 km/h)
Stall speed: 124 mph (108 knots, 200 km/h)
Combat radius: 950 mi (825 nm, 1,530 km) with 5,250 lb (2,380 kg) of bombs
Ferry range: 2,720 mi (2,360 nm, 4,380 km)
Service ceiling: 45,100 ft (13,745 m)
Rate of climb: 6,180 ft/min (31.4 m/s)
Wing loading: 42 lb/ft² (205 kg/m²)
Thrust/weight: 0.36
Lift-to-drag ratio: 15.0
