Mission
The V-22 Osprey is a joint service multirole combat aircraft utilizing tiltrotor technology to combine the vertical performance of a helicopter with the speed and range of a fixed-wing aircraft. With its rotors in vertical position, it can take off, land and hover like a helicopter. Once airborne, it can convert to a turboprop airplane capable of high-speed, high-altitude flight. This combination results in global reach capabilities that allow the V-22 to fill an operational niche unlike any other aircraft.

General characteristics
-Propulsion Two Rolls-Royce AE1107C, 6,150 shp (4,586 kW) each
-Length Fuselage: 57.3 ft. (17.48.20 m); Stowed: 63.0 ft. (19.20 m)
-Width Rotors turning: 84.6 ft. (25.78 m); Stowed: 18.4 ft. (5.61 m)
-Height Nacelles vertical: 22.1 ft. (6.73 m); Stabilizer: 17.9 ft. (5.46 m)
-Rotor Diameter: 38.1 ft (11.6 m)
-Vertical Takeoff Max Gross Weight: 52,600 lbs. (23,859 kg)
-Max Cruise Speed: 270 kts (500 km/h) SL
-Mission Radius: 428 nm – MV-22 Blk C with 24 troops, ramp mounted weapon system, SL STD, 20 min loiter time
-Cockpit - crew seats: 2 MV / 3 CV
-Arnament: 7.62×51mm NATO (.308 in caliber) M240 machine gun or .50 in caliber (12.7 mm) M2 machine gun

Source: www.boeing.com
Photo courtesy: www.boeing.com
